Power Valve: Regulator Valve VEX1 Series

Operation type

Air operated, External pilot solenoid

Fluid

Air

Max. operating pressure

1.0 MPa

Set pressure Air operated

range

Air operated

0.05 to 0.9 MPa

Solenoid

0.05 to 0.7 MPa

0.05 to 0.9 MPa

Ambient and fluid temp.

0 to 50°C(Air operated: 0 to 60°C) No condensation

Hysteresis

0.03 MPa

Repeatability

0.01 MPa

Sensitivity

0.01 MPa

Mounting

Free

Lubrication

Not required (Use turbine oil Class 1 lSO VG32, if lubricated.）

Port size

Port

01

02

01

02

02

03

04

04

06

10

10

12

14

20

1(P)

1/8

1/4

1/8

1/4

1/4

3/8

1/2

1/2

3/4

1

1

1 1/4

1 1/2

2

2(A)

3(R)

1 1/4

2

Weight (kg)

Air operated

0.1

0.2

0.4

1.3

1.9

3.9

Solenoid

0.2

0.3

0.5

1.4

2.0

4.0
