・The guide pitch has been doubled
・The allowable rotational torque of the plate has been improved.
The non-rotating accuracy of the plate has been improved.
・Equivalent weight to the basic type
| Bore Size | 20 | 25 | 32 | 40 | 50 | 63 |
| Action | Double Acting | |||||
| Fluid | Air | |||||
| Proof Pressure | 1.5MPa | |||||
| Max Operating pressure | 1.0MPa | |||||
| Min Operating pressure | 0.1MPa | |||||
| Piston Speed | 50 to 500 mm/s | |||||
| Cushion | Rubber bumper on both ends | |||||
| Lubricaiton | Not required(Non-lube) | |||||
| Bmbient and fluid temperature | -10 to 60℃（No freezing） | |||||
