2P Series 2/2 Way Solenoid Valve

Working Medium

Air Water Oil gas

Motion Pattern

D irect Drive Type

Type

Normal Close Type

Aperture of Flow Rate(mm)

2.5

CV Value

0.23

Joint Pipe Bore

1/8″

1/4″

Operation Fluid Viscosity

20 CST (Below)

Working-pressure

0~0.7 MPa

Max. Pressure Resistance

1.0 MPa

Operating Temperature

-5~80℃

Voltage Range

±10%

Material of Body

Engineering Plastic

Material of Oil Seal

NBR or VITON
