2V Series 2/2 Way Solenoid Valve

Morking Medium

Air Water Oil

Motion Pattem

Direct Drive Type

Guide Type

Type

Normal Close Type

Aperture of Flow Rate(mm)

1.0

2.5

13

25

CV Valye

0.10

0.23

6.2

23

Port Size

M4X0.7

G1/8"

G1/4"

G3/8"

G1/2"

G3/4"

G1"

Operation Fluid Viscosity

20 CST (Below)

Working-pressure

Air,Water,Oil 0~0.8MPa/ Air,Water,Oil 0.05~0.7MPa

Max.Pressure Resistance

1.2

1.6

1.0

Operating Temperature Range

-10~+80

Voltage Range

10%

Protect Class

IP65

Power Consumption

AC:4.5VA DC:3W

Insulation

F Level

Material of Body

Aluminum or Brass

Brass

Material of Oil Seal

NBR or VITON

NBR or VITON

Shortest Excitation Time

0.05 Second
